Qoltec Hybrid Solar Inverter Off-Grid 6kVA | 6kW | 120A | MPPT | LCD | Wi-Fi | BMS | Sinus
Consegne Rapide e Sicure con i migliori Corrieri Internazionali
![]()
Advertising [Product3rdColumn]
Clicca per vedere
Clicca per vedere
Clicca per Vedere

How does the hybrid inverter work in off-grid mode ?
The performance of a photovoltaic system depends on the selection of the right inverter, or solar inverter. The inverter performs a key function in this system, changing the DC current generated by the photovoltaic panels into AC current used by household appliances. The off-grid hybrid inverter combines the photovoltaic system, the energy storage and the power grid.
It uses excess solar energy to power consumers and charge the battery. When energy production is greater than current demand, the excess current can be transferred to charge LiFePO4, AGM, GEL batteries, allowing energy to be stored for later use, such as at night or on cloudy days. The hybrid inverter can automatically switch to off-grid mode, supplying energy from the batteries.
- Colore del prodotto
- Argento
- Larghezza
- 323 mm
- Profondità
- 323 mm
- Altezza
- 360 mm
- Peso
- 5,6 kg
- Potenza
- 1500 W
- Capacità
- 10 L
- Tipo di prodotto
- Friggitrice ad aria calda
- Display incorporato
- Sì
- Tipo di controllo
- Touch
- Funzione frittura
- Sì
- Funzione cottura al forno
- Sì
- Tipo di costruzione
- Singolo
- Contenitore rimovibile
- Sì
- Componenti lavabili in lavastoviglie
- Sì
- Capacità friggitrice
- 0,65 kg
- Colour
- White, black
- Screen
- LCD, touch panel
- Interface
- RS-232, Wi-fi, micro USB, BMS
- Type
- Off-Grid
- Additional information
- Support LiFePO4 AGM, GEL, Deep cycle batteries
Support BMS - Noise level
- 45 dB
- Cooling system
- 2 x fan
- transfer time
- 10 ms (PC) 20 ms (home appliances)
- Protection
- Anti-short-circuit
Against overheating
Against overload
Against overload - Producer
- Qoltec
- Efficiency
- 93%
- Maximum charging current
- 27A
- Rated Power
- 6000VA/6000W
- Battery voltage
- 48VDC
- Working frequency
- 60/50 HZ (auto detection)
- Phase
- 1
- Nominal Input voltage
- 230VAC
- Waveform
- Pure sine wave
- Type of charging
- MPPT
- Battery overcharge protection
- Yes
- Maximum battery charging current from PV
- 120A
- Maximum PV array open circuit power
- 6000W
- MPPT STARTING VOLTAGE
- 60VDC +/- 10VDC
- MPPT operating voltage range
- 60 ~ 450VDC
- Maximum PV array open circuit voltage
- 500VDC
- Variable charging voltage
- 54VDC
- Work without battery
- Yes
- Maximum AC input voltage
- 300VAC
